PIPE & TUBE BENDING & FORMING |
| |
|
Machines>
Metal Process Working Machineries>
Pipe Bending> French Mnufacturer |
|
French Manufacturer
European Leadership in Big
Size Pipes |
|
|
|
Super SD-MP 150
Petroleum Series |
|
Electrically Powered
- Complete bender Super SD-MP 150 - Petroleum serie's - 100
tons jack - Integrated hydraulic pump electrically powered -
Three-phase 400 Volt - 3 KW
- One pair of Cheeks for API or ASA pipes and side formers
-
- Gross Net Weight of the jack box : 250 Kg -
- Dimensions of the jack box : 1250 x 800 x 800 -
- The cheeks and side formers are delivered on a pallet :
4500 x 1300 x 800 x mm
- Gross Weight : 760 Kg -
Gasoline Engine Powered
- Complete bender Super SD-MEP 150 - Petroleum serie's
- 100 tons jack - Integrated hydraulic pump with HONDA
gasoline engine - 5 Hp
- delivered in a reinforced wooden box
- One pair of Cheeks for API or ASA pipes and side
formers -
- Gross Net Weight of the jack box : 250 Kg -
- Dimensions of the jack box : 1250 x 800 x 800 -
- The cheeks and side formers are delivered on a
pallet : 4500 x 1300 x 800 x mm
- Gross Weight : 780 Kg -
Toolings
- 4" - Ø 114,3 - Jack 100 Tons Petroleum Series'
For bending API or ASA pipe
- 5" - Ø 141,3 - Jack 100 Tons Petroleum Series'
For bending API or ASA pipe
- 6" - Ø 168,3 - Jack 100 Tons Petroleum Series'
For bending API or ASA pipe
- 8" - Ø 219 - Jack 100 Tons Petroleum Series' For
bending API or ASA pipe
- 10" - Ø 273 - for 100 Tons jack For
bending tubes API & ASA
- 12" - Ø 323 - Jack 100 Tons Petroleum Series'
For bending API or ASA pipe
|
| |
